Diffs
-
CROWNWHEEL BOLT
- R90.76 excl VAT
- This is an aftermarket high tensile shouldered bolt that engine and gearbox tuners are using, as the original shape head and high tensile type bolt is no longer available. For holding the crown wheel to the differential housing. Sold individually 6 required per gearbox
-
Differential Roller Rhp Manufacture
- R779.13 excl VAT
- Genuine RHP as originally fitted to every production Mini. Two of these main diff carrying bearings are required in the gearbox and this new steel caged type fits either way round. Should be pre loaded by 1-2 thou.
-
Differential Thrust Washer 8 Thou Oversize
- R83.08 excl VAT
- Genuine Rover fibre type are now 48 thou thick which is so tight it will probably lock your diff up, they used to originally be .035 thou. These are 43 thou oversize type for worn units but the correct size of 35 thou is available as BTA101. Sold singly
-
LSD Crown wheel bolts
- R826.00 excl VAT
- Competition crown wheel bolts to fit with LSD-type crown wheels only. CNC machined from EN24T with reduced head height for gearbox clearance, the overall length is also pre-finished for exact fitment of most competition LSDs. Torque to 55lb.ft Please note, these bolts will not suit the Quaife ATB or MED Helical Gear unit - for these applications see the ARP…
-
Differential Fibre Thrust Washer Standard Size
- R83.08 excl VAT
- Genuine Rover are now 48 thou thick which is so tight they can lock up your differential. The originals were .035 thou. These are machined down to be exactly the correct size required but we also stock oversize 43 thou type which are available as‚ BTA102‚ for worn units. We have never required anything larger that was servicable. Sold singly…
-
Primary Gear Rear Bush Top Hat Type
- R279.49 excl VAT
- The gearbox diff side plate bonze colour bush for all except auto and cooper S with hardy spicer output shafts. Sold singly 2 required per gearbox.
-
MED Hardy spicer output shafts – lsd
- R5,327.00 excl VAT
- The MED Hardy Spicer Output Shafts are supplied complete with heavy-duty retaining washers and circlips. These connect the spline of an NXG Limited-slip Differential unit to the Hardy Spicer coupling bolt pattern, so you upgrade to heavy duty Hardy Spicer Couplings and MED 300M Driveshafts. Sold in pairs. Please note - these are designed to suit the smaller pot joint…
-
MINI DOG ENGAGEMENT GEAR KIT (SUPERFINISHED)
- R52,570.00 excl VAT
- The MED gear kit is machined in the UK to exacting tolerances, with a five-dog engagement for slick, confident gear changes and excellent longevity for full-competition usage. The was designed to run with very little backlash, to eliminate gear tooth wear commonly associated with other dog-engagements gear kits. The MED design has been continually developed and enhanced over 15 years…
-
NXG LSD DIFFERENTIAL – MINI
- R20,629.52 excl VAT
- The latest NXG limited-slip differential offers the strongest, most progressive and versatile LSD unit on the market for competition Minis. The NXG plate pack runs on eight active surfaces, giving maximum surface area and contact during use. Dual ramp angles allow an internal change from the standard 30/90-degrees to 40/90-degrees, to adjust aggression under acceleration and best suit your driving…
-
POT JOINTS LSD TYPE
- R4,873.68 excl VAT
- The MED pot joint LSD output shaft converts from the spline of a limited-slip differential to a regular Mini pot joint type. This allows you to connect standard pot joint driveshafts to an LSD such as the NXG differential.
-
Thrust Washer For Planet Gear With Lip A Plus
- R103.41 excl VAT
- The latest model Mini differential still use thrust washers on the spider gears but now have a tab on one end to prevent them from rotating on the cage side of the diff. The cage of course is cast while the gear itself is much harder and thus the whole assembly now lasts much longer. Check the casing seating where…
-
Differential Performance Pin With Molybdenum Coating
- R828.42 excl VAT
- Competition quality replacement diff pin with anti wear MOLYBDENUM coating for planet wheel surfaces and still cheaper than a standard Rover pin. Recommended for all differential rebuilds.Pay special attention to the condition of the planet wheels when rebuilding.This moly coated pin MUST NOT be used with the specially bushed planet wheels DAM6624BUSHED as it causes undue wear The bushed planet…
-
Gear Box Differential Pinion Locktab
- R70.68 excl VAT
- Gearbox differential pinion locktab to secure it on the mainshaft for all manual gearboxes.
-
Dam6624 Planet Gear With Metal Bush Fitted
- R890.52 excl VAT
- This is the standard DAM6624 differential planet gear but with a special bush inserted in the middle to run on our upgraded diff pin C-BTA166, which alleviates all the play and makes a smoother precision surface for longevity. This bushed planet wheel is part of our diff pin kit C-BTA167. These bushed planet wheels must not be used on our…
-
Diff Cage Rollpin
- R9.36 excl VAT
- Special pin to hold the differential cross pin in place in the housing.
